Quick Start Spring Batch with Spring Boot 3

 ContentsIntroduction
Target Audience
Repository Setup
Skeleton Batch Guide
DB and CSV Batch Guide
Continuous Integration
Conclusion
 IntroductionHello, I'm Miyashita, an engineer from KINTO Technologies' Common Service Development Group[1][2][3][4][5].
While developing batch processes with Spring Boot 3, I encountered several challenges with Spring Batch's class structure and annotations. The transition to Spring Boot 3 presented additional complexities, particularly with multi-database configurations and error handling.
A particular challenge was the lack of Japanese documentation for Spring Boot 3. While referring to the official documentation, I had trouble finding configurations that matched my requirements and encountered issues with multi-database setup and error handling. This led to a cycle of trial and error, making me acutely aware of the challenges in building a batch process from scratch.
In this article, I've compiled information to help others facing similar challenges implement Spring Batch more smoothly:
Spring Boot 3 Batch Skeleton
Immediate deployment through GitHub clone and run
Ready for business logic implementation
Pre-configured for production use
Common Batch Processing Use Cases

In addition to the skeleton, I'll introduce sample code for batch processing utilizing a multi-database configuration:
Batch process for exporting DB records to CSV
Batch process for importing CSV data to DB
I hope this article helps make Spring Batch implementation and development easier.
 Target AudienceThis guide is designed for developers who are:
✓ New to Spring Batch 5 framework implementation

✓ Returning to Spring Batch after a hiatus

✓ Migrating from Spring Boot 2 Batch due to end of support

✓ Experienced with Java main method batches but need Spring Batch

✓ Seeking rapid batch development solutions
 Repository Setuphttps://github.com/kinto-technologies/SpringBoot3BatchStarter/

This is my repository. Please clone it and import it into your IDE.

For GUI-based operations, use GitHub Desktop,
 Repository StructureThe repository is structured as follows:
.
├── gradlew                # Gradle wrapper for build automation
├── settings.gradle
├── compose.yaml           # Docker Compose configuration
├── init-scripts           # Database initialization
│   ├── 1-create-table.sql
│   └── 2-insert-data.sql
├── dbAndCsvBatch          # DB/CSV processing implementation
│   ├── build.gradle
│   └── src
│       ├── main
│       └── test
└── skeletonBatch          # Basic batch implementation
    ├── build.gradle
    └── src
        ├── main
        └── test
 Skeleton Batch Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/tree/main/skeletonBatch
This is a skeleton code that becomes a complete batch process just by adding business logic. It consists of only the necessary code components.
 Core Concepts: Jobs and StepsSpring Batch is built on two fundamental concepts: Jobs and Steps.
 JobsA Job represents the complete batch process:
Contains one or multiple Steps
Manages batch execution flow
Supports sequential and parallel processing
Job Capabilities


Capability
Implementation
Example


Sequential
Chain multiple jobs
Daily data processing pipeline

Error Handling
Define recovery actions
Automated error notifications

Concurrent
Run multiple jobs simultaneously
Parallel data processing

Parallel
Multiple instances of same job
Large dataset processing

 StepA Step represents a processing unit within a job. One job can register multiple steps, and step behavior can be designed flexibly like jobs.
 Implementation MethodSteps can be implemented using either Chunk or Tasklet processing.
 1. Chunk ProcessingThis is a method for efficiently processing large volumes of data.
 Implementation CharacteristicsProcessing is divided into three phases:
Reader: Reads data in fixed quantities
Example: Reading 100 lines at a time from CSV file using FlatFileItemReader
Processor: Processes data one item at a time
Example: Converting date formats using CustomProcessor
Writer: Outputs data in bulk
Example: Bulk INSERT to DB using JdbcBatchItemWriter
Transactions are committed by chunk size (e.g., 100 items). This means that even if an error occurs midway, the successfully completed chunks are committed.
 2.　Tasklet ProcessingThis is a method for executing simple, single-unit processes.
 CharacteristicsSimple implementation
Easy to understand processing flow
Straightforward debugging
 Choosing Between Implementation Methods

Aspect
Chunk
Tasklet


Data Volume
Suitable for large volumes
Suitable for small volumes

Processing Complexity
Suitable for complex processing
Suitable for simple processing

Management Cost
Higher
Lower

Debugging
Somewhat complex
Easy

Transaction
By chunk
By process unit

 SummaryJob is the management unit for the entire batch process
Step is the execution unit for specific processes
Chunk is suitable for efficient processing of large data volumes
Tasklet is optimal for simple processing
Choose between Chunk and Tasklet based on processing requirements
!Key Point

For simple batches that don't require complex processing, choose Tasklet without hesitation.

This skeleton batch also adopts Tasklet processing.
!Note

In official documentation and many web articles, chunk processing is explained as the basic approach of Spring Batch, which often leads beginners to mistakenly think they must use chunks. This frequently results in implementing with chunks first, then realizing later that Tasklet would have been more appropriate, causing rework.
 YAML Configuration and Spring Batch Management TablesLet's first explain the basic configuration needed to run Spring Batch in batch-dedicated mode.
 YAML Configurationhttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/skeletonBatch/src/main/resources/application.yml
This configuration allows the Spring Boot application to run in serverless mode.

While typical Spring Boot applications maintain their process by starting servers like Tomcat, this is unnecessary for batch processing. With this configuration, the process terminates when batch processing completes.
 Spring Batch Management TablesSpring Batch requires management tables in a database to record execution results. However, managing databases and tables can be cumbersome. Moreover, you might need to run batches in environments without databases. In such cases, using H2 in-memory database is recommended. When the process ends:
Memory is released
Database and tables are cleared
Next execution starts with a fresh state
H2 is automatically configured if no database settings are specified in application.yml
!Benefits of Persistent Storage

While using H2 is convenient for development, using a persistent database allows you to:
Maintain execution history
Resume from interruptions
Track batch execution status
 Job Class Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/skeletonBatch/src/main/java/com/example/batch/job/SampleJob.java#L16-L41
This is the core class for registering and executing Jobs in Spring Batch.
 Class Definition Key Points@Configuration
Recognized as a Spring Batch configuration class
Indicates that this class provides Spring configuration
Required annotation for Job definition classes
@Bean
Applied to methods that generate objects managed by Spring Framework
In this case, allows Spring to manage the Job created by createSampleJob
The Job instance is used during batch execution
!Important Note

By default, the method name is used as the Bean name. If you copy this class to create a new Job, using the same method name will cause an error. To avoid this, specify a unique name like @Bean("jobName"). This is a common pitfall to watch out for.
 Dependency Class RolesJobRepository: Manages job execution state
PlatformTransactionManager: Maintains database consistency
SampleLogic: Handles actual business processing
 Processing FlowOutput job registration start log
Create Step (define processing unit)
Create Job and register Step
Output job registration completion log
 Transaction ManagementNormal completion: Database changes are confirmed when all processing succeeds
Abnormal termination: Database changes are rolled back when errors occur
This ensures the reliability of batch processing operations.
 Logic Class Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/skeletonBatch/src/main/java/com/example/batch/logic/SampleLogic.java#L13-L35
This class defines the actual processing content of the batch.
 Class Definition Key Points@Component
Makes this class manageable by Spring
Allows usage with @Autowired in other classes
Tasklet Interface
Interface representing Spring Batch processing unit
Implement actual processing in the execute method
 Processing FlowOutput batch processing start log
Call SampleService's process method
Output completion log on normal termination
Log exception and re-throw on error occurrence
Output batch processing end log
 Error HandlingNormal completion: Return RepeatStatus.FINISHED to complete batch
Abnormal termination: Catch exception, log it, and notify upper layer
!Implementation Point

While this class delegates processing to SampleService, you can implement simple processing directly in the execute method.
 Service Class Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/skeletonBatch/src/main/java/com/example/batch/service/SampleService.java#L8-L23
This class is for implementing actual business logic.
 Class Definition Key Points@Service
Recognized as a Spring Framework service class
Indicates this class implements business logic
process Method
Method for implementing batch business processing
Includes start and completion log output
!Implementation Point

This class is completely independent from Spring Batch classes and interfaces. This means:
Focus purely on business logic implementation
Easy to write JUnit tests
Easily reusable in other projects
 Customization OptionsYou can modify:
Class name
Method name
Arguments and return values
Business logic implementation (e.g., data validation, transformation, external system integration)
This concludes our explanation of the main skeleton batch classes. This loosely coupled design makes the batch easy to maintain and test.
 Running the Batch Running from IDEStart the BatchApp class. It works like a regular Spring Boot application with no special startup arguments required.
 Running via Gradle from TerminalExecute the following command:
./gradlew :skeletonBatch:bootRun
 Running by Generating and Executing JAR FileGradle's default task is configured to generate a JAR file. Execute as follows:
cd skeletonBatch
../gradlew

java -jar build/libs/batch-skeleton*.jar
 Checking Execution LogsLet's examine the Spring Batch execution flow through the logs.
 1. Job Registration Check batch.log
----------- Registering job: sample -----------
----------- Job registered successfully: sample-job -----------
During Spring Boot startup, the batch job 'sample-job' was successfully registered.
 2. Batch Processing Execution batch.log
Started BatchApp in 0.456 seconds (process running for 0.616)
Running default command line with: []
Job: [SimpleJob: [name=sample-job]] launched with the following parameters: [{}]
Executing step: [processing-step]
----------- START ----------- Batch Processing -----------
--- Starting batch process ---
--- Batch process completed ---
Processing completed successfully
-----------  END  ----------- Batch Processing -----------
Step: [processing-step] executed in 3ms
Job: [SimpleJob: [name=sample-job]] completed with the following parameters: [{}] and the following status: [COMPLETED] in 9ms
 Important Points from Logs:'sample-job' executed and 'processing-step' started
START and END markers clearly show processing boundaries
Step completed successfully and job finished with COMPLETED status
Application terminated normally
 Skeleton Batch Summary AdvantagesComplete batch process by just adding business logic
Integration with schedulers like cron using generated JAR file
High maintainability through simple structure
!Development Support

Spring Batch development often faces issues like:
Missing annotations
Configuration mistakes
Complex error messages
This skeleton helps you avoid these problems and focus on implementing business logic.
This skeleton code aims to contribute to more efficient batch development.
 DB and CSV Batch Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/tree/main/dbAndCsvBatch
 OverviewThis project includes two batch processes:
DB to CSV Export
Exports database records to CSV format
Customizable extraction conditions via startup arguments
Works with default settings
CSV to DB Import
Bulk imports CSV data into database
Requires CSV file, so run export batch first
 Local Database SetupThis batch uses a MySQL local database. Follow these steps for setup:
Start MySQL Container

docker compose up -d
!If Docker is not installed, download and install it from the Docker official website.
Verify Setup

Connect to MySQL container and check sample data:

docker exec -it mysql-container mysql -u sampleuser -psamplepassword sampledb
Run sample query:
 sql
mysql>
SELECT *
FROM member
WHERE delete_flag = 0
  AND type IN (1, 2, 3)
ORDER BY type ASC;

mysql> exit
Bye
 Entity Class Auto-generationAfter cloning the GitHub repository, you might encounter a "Entity class not found" error. This occurs because jOOQ needs to auto-generate Entity classes.
 Running Auto-generationEither command will generate Entity classes:
# Execute default task
cd dbAndCsvBatch/
../gradlew

# Or directly execute jOOQ generation
../gradlew generateJooq
The build.gradle is configured for immediate use without additional settings. Default task execution includes:
Cleanup of build results
Java code formatting (Google Java Format)
Entity class auto-generation (jOOQ plugin)
Compilation
Static analysis and testing (JUnit, coverage, SpotBugs)
Executable JAR generation
 Generated Entity ClassesCheck generated Entity classes with:
tree dbAndCsvBatch/build/generated-src

# If tree command is not installed:
ls -R dbAndCsvBatch/build/generated-src
 Example output:
dbAndCsvBatch/build/generated-src/jooq
└── main
    └── com
        └── example
            └── batch
                └── jooq
                    ├── DefaultCatalog.java
                    ├── Keys.java
                    ├── Sampledb.java
                    ├── Tables.java
                    └── tables
                        ├── Member.java
                        └── records
                            └── MemberRecord.java

!Since jOOQ plugin auto-generates code from database schema during build, managing it with Git can cause conflicts when schema changes. Therefore, generated code should not be included in Git management.
 Handling "Class Not Found" ErrorsYour IDE might report Entity classes not found. Resolve this by either:
Add generated-src/jooq to IDE's build path
Copy classes from generated-src/jooq to dbAndCsvBatch/src/main/java
 Production Environment Setuphttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/build.gradle#L101-L124
!Change connection settings to your DEV/STG database
Or add your production CREATE TABLE statements to Docker Compose initialization SQL

jooq gradle plugin website
 Multi-database ConfigurationThis batch uses a dual database configuration:
H2 (In-memory Database)
Used for Spring Batch management tables
Resets when process ends
Ideal for development and testing
MySQL (Business Logic Database)
Used for actual business data processing
Runs in Docker container
 Configuration File (application-local.yml)Spring Boot's configuration file defines two databases under spring.datasource.
https://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/resources/application-local.yml
The configuration file includes:
Two database settings
Profile suffixes (local and server)
Runtime profile selection capability
The server profile is intended for your production MySQL server settings.
 Data Source Configuration Classhttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/java/com/example/batch/config/DataSourceConfig.java#L11-L37
 Key Annotations@Configuration
Marks class as Spring configuration
Spring manages beans defined here
@ConfigurationProperties
Maps YAML settings to class properties
Example: maps 'spring.datasource.mysqlmain'
@BatchDataSource
Specifies data source for Spring Batch tables
Applied to H2 database
@Primary
Designates default data source
Applied to MySQL data source
 Job Class Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/java/com/example/batch/job/DbToCsvJob.java#L31-L39
 New Features AddedAutomatic Run ID Increment
  .incrementer(new RunIdIncrementer())
Automatically increments job execution number (run.id)
Used for execution history management
!While this sample uses H2 (in-memory DB) making the run ID transient, this is a standard implementation pattern when using persistent databases.
Listener Integration
  .listener(listener)
Add processing before and after job execution
Useful for logging, email notifications, etc.
 Logic Class Guidehttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/java/com/example/batch/logic/DbToCsvLogic.java#L18-L49
This example demonstrates basic logging implementation, but you can add custom processing like error handling and notifications.
 Parameter Configuration@Value("${batch.types:2,3,4}")
private String typesConfig;
Uses 2,3,4 as default values even without application.yml
Can be overridden by passing --batch.types=1,2 at runtime
 Error Handlingcontribution.setExitStatus(ExitStatus.FAILED);
Explicitly sets failure status on error
Automatically sets COMPLETED status on normal completion
 Repository Class and jOOQ Guide About jOOQjooq is a library that allows writing SQL as Java code:
Express SQL syntax directly in Java code
Auto-generate Entity classes from table definitions
Type-safe SQL operations
 Select Processinghttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/java/com/example/batch/repository/MemberRepository.java#L18-L25
Key FeaturesSQL-like Syntax
Direct expression of SQL in Java code
Leverage existing SQL knowledge
Auto-generated Class Usage
MEMBER: Represents table definition (column names, etc.)
MemberRecord: For record mapping
 Bulk Insert Processinghttps://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/java/com/example/batch/repository/MemberRepository.java#L54-L69
 Bulk Insert FeaturesRegisters multiple records at once instead of one-by-one
Common in batch processing to reduce database load
!While not used in this batch, example code for insert, update, and delete operations is included.

You can quickly adapt the repository class by replacing table and column names to match your business environment.
 Repository Class SummaryUse jOOQ's Gradle plugin to auto-generate entities from database schema
Auto-generated classes enable type-safe SQL writing in Java
Easy to handle schema changes - just regenerate classes
!Spring Batch supports multiple database operation methods:
Hibernate (JPA)
Powerful database abstraction
Easy Spring Boot integration
May have overhead with large datasets
MyBatis
Ideal for direct SQL management
Strong dynamic query support
May reduce maintainability
Spring JdbcTemplate
Lightweight database operations
Good for simple queries
Can be verbose
!Note

Choose the appropriate method based on:
Project requirements
Team skill set
Direct SQL execution if needed
 DB to CSV Batch Execution GuideRun the DB to CSV batch following similar steps as the skeleton batch.
 Running via Gradle
./gradlew :dbAndCsvBatch:bootRun
 Running JAR File
cd dbAndCsvBatch/
../gradlew
java -jar build/libs/batch-dbAndCsv*.jar
Running without arguments produces this error:
 batch.log
org.springframework.beans.factory.BeanCreationException: Error creating bean with name 'jobLauncherApplicationRunner' defined in class path resource [org/springframework/boot/autoconfigure/batch/BatchAutoConfiguration.class]: Job name must be specified in case of multiple jobs
	at com.example.batch.DbAndCsvBatchApp.main(DbAndCsvBatchApp.java:)

Caused by: java.lang.IllegalArgumentException: Job name must be specified in case of multiple jobs
 Why This Error OccursUnlike the skeleton batch with a single job, this project contains multiple jobs:
CSV to DB: Importing CSV data into database
DB to CSV: Exporting database data to CSV
The framework cannot determine which job to execute without explicit specification.
 Running with ArgumentsSpecify the job name and environment in startup arguments:
--spring.batch.job.name=DB_TO_CSV --spring.profiles.active=local
--spring.batch.job.name=DB_TO_CSV: Specifies which job to run
--spring.profiles.active=local: Activates local environment settings
 Example Commands
# Using Gradle
./gradlew :dbAndCsvBatch:bootRun --args="--spring.batch.job.name=DB_TO_CSV --spring.profiles.active=local"

# Using JAR directly
cd dbAndCsvBatch/
java -jar build/libs/batch-dbAndCsv*.jar --spring.batch.job.name=DB_TO_CSV --spring.profiles.active=local
 Examining the LogsLet's check the execution logs:
 1. Initial Startup Log batch.log
##### KEY:"sun.java.command", VALUE:"com.example.batch.DbAndCsvBatchApp --spring.batch.job.name=DB_TO_CSV --spring.profiles.active=local"
##### Spring Batch ##### - Job: DB_TO_CSV, Profile: local
This confirms our startup arguments were correctly received.
 2. Job Start Log batch.log
----------- JOB [Job Name:DB_TO_CSV] START! -----------
Executing step: [DB_TO_CSV-step]
Fetching members with types = [1, 2, 3]
Shows BatchNotificationListener's beforeJob method execution and configured types.
 3. Database Operation Log batch.log
-> with bind values      : select `sampledb`.`member`.`id`, `sampledb`.`member`.`type`, `sampledb`.`member`.`name`, `sampledb`.`member`.`email`, `sampledb`.`member`.`phone`, `sampledb`.`member`.`address`, `sampledb`.`member`.`delete_flag`, `sampledb`.`member`.`created_at`, `sampledb`.`member`.`updated_at`
from `sampledb`.`member`
where (`sampledb`.`member`.`delete_flag` = 0 and `sampledb`.`member`.`type` in (1, 2, 3)) order by `sampledb`.`member`.`type`

Version                  : Database version is supported by dialect MYSQL: 9.1.0
Fetched result           : +----+----+----------+----------------------+----------+-----------------------------+-----------+-------------------+-------------------+
                         : |  id|type|name      |email                 |phone     |address                      |delete_flag|created_at         |updated_at         |
                         : +----+----+----------+----------------------+----------+-----------------------------+-----------+-------------------+-------------------+
                         : |   1|   1|John Doe  |john.doe@example.com  |1234567890|123 Main St, City, Country   |          0|2024-12-07T09:46:07|2024-12-07T09:46:07|
                         : |   2|   1|Jane Smith|jane.smith@example.com|0987654321|456 Oak St, Town, Country    |          0|2024-12-07T09:46:07|2024-12-07T09:46:07|
                         : |  26|   1|John Doe  |john.doe@example.com  |1234567890|123 Main St, City, Country   |          0|2024-12-09T05:36:37|2024-12-09T05:36:37|
                         : |  27|   1|Jane Smith|jane.smith@example.com|0987654321|456 Oak St, Town, Country    |          0|2024-12-09T05:36:37|2024-12-09T05:36:37|
                         : |   3|   2|ABC Corp  |contact@abccorp.com   |5678901234|789 Pine St, Village, Country|          0|2024-12-07T09:46:07|2024-12-07T09:46:07|
                         : +----+----+----------+----------------------+----------+-----------------------------+-----------+-------------------+-------------------+
Fetched row(s)           : 5 (or more)
Batch process completed successfully.
Step: [DB_TO_CSV-step] executed in 193ms
Job: [SimpleJob: [name=DB_TO_CSV]] completed with the following parameters: [{'run.id':'{value=1, type=class java.lang.Long, identifying=true}'}] and the following status: [COMPLETED] in 212ms
----------- JOB [Job Name:DB_TO_CSV] FINISHED! status:[COMPLETED] -----------
https://github.com/kinto-technologies/SpringBoot3BatchStarter/blob/main/dbAndCsvBatch/src/main/resources/logback.xml#L21-L22
jOOQ's query and result logging is enabled in logback.xml for easier debugging.
 Generated CSV Check members.csv
"id","type","name","email","phone","address","deleteFlag","createdAt","updatedAt"
"1","1","John Doe","john.doe@example.com","1234567890","123 Main St, City, Country","0","2024-12-11T06:05:26","2024-12-11T06:05:26"
"2","1","Jane Smith","jane.smith@example.com","0987654321","456 Oak St, Town, Country","0","2024-12-11T06:05:26","2024-12-11T06:05:26"
"3","2","ABC Corp","contact@abccorp.com","5678901234","789 Pine St, Village, Country","0","2024-12-11T06:05:26","2024-12-11T06:05:26"
"5","3","Alice Premium","alice.premium@example.com","4561237890","987 Maple St, City, Country","0","2024-12-11T06:05:26","2024-12-11T06:05:26"
"6","3","Charlie Davis","charlie.davis@example.com","1112223333",,"0","2024-12-11T06:05:26","2024-12-11T06:05:26"
The CSV file is generated using the OpenCSV library.
opencsv website
 Testing Runtime Argument OverrideLet's try customizing the types parameter at runtime:

--spring.batch.job.name=DB_TO_CSV --batch.types=4,5 --spring.profiles.active=local
 Log Output batch.log
-> with bind values      : select `sampledb`.`member`.`id`, `sampledb`.`member`.`type`, `sampledb`.`member`.`name`, `sampledb`.`member`.`email`, `sampledb`.`member`.`phone`, `sampledb`.`member`.`address`, `sampledb`.`member`.`delete_flag`, `sampledb`.`member`.`created_at`, `sampledb`.`member`.`updated_at` from `sampledb`.`member` where (`sampledb`.`member`.`delete_flag` = 0 and
`sampledb`.`member`.`type` in (4, 5)) order by `sampledb`.`member`.`type`
This confirms that the configuration file values were successfully overridden by command line arguments.
 CSV to DB Batch ExecutionRun the batch with the specified job name:
--spring.batch.job.name=CSV_TO_DB --spring.profiles.active=local
Log Output
 batch.log
insert into `sampledb`.`member` (`name`, `email`, `phone`, `address`, `type`) values
('Premium Corp', 'premium@corporate.com', '8889997777', '555 High St, City, Country', 4),
('Elite Ltd', 'elite@elitecorp.com', '4445556666', '777 Sky Ave, Town, Country', 4),
('Guest User1', 'guest1@example.com', '', 'Guest Address 1, City, Country', 5),
('Guest User2', 'guest2@example.com', '9998887777', '', 5)

Affected row(s)          : 4
This confirms successful bulk insertion of records.
 Continuous IntegrationThis project implements CI (Continuous Integration) using GitHub Actions. Quality management is efficiently handled through automated processing triggered by code pushes or pull requests.
 Main WorkflowMySQL Setup
Launch MySQL using Docker Compose
Verify required tables
JDK 21 Setup
Install Java 21
Configure build environment
jOOQ Class Generation
Auto-generate entity classes from database schema
Build and Test
Execute Gradle build
Run quality checks:
JUnit tests
Jacoco coverage
SpotBugs analysis

This workflow enables:
Immediate detection of compilation errors
Quick identification of JUnit test failures
Rapid response to issues
Consistent code quality maintenance
Dynamic Badge Updates
When the build and tests succeed, a dynamic badge is displayed on the GitHub README, indicating the status of the project.

 Code Coverage VisualizationThis project uses Codecov to measure and visualize test coverage. Coverage reports are automatically generated during pull requests, and the coverage rate can be checked via this badge:
This enables:
Visual tracking of test coverage
Quick detection of coverage changes
Enhanced transparency in quality management

Detailed coverage reports are available on the Codecov dashboard.
 ConclusionWe hope you found this guide helpful!
This project provides:
Skeleton code foundation for efficient Spring Batch development
Common use cases like "DB to CSV" and "CSV to DB"
Flexible customization through database settings and CSV layouts
We hope this skeleton helps streamline your batch development by allowing you to focus on business logic implementation.
If you found this article helpful and got your Spring Batch up and running quickly, we would appreciate a ⭐ on our GitHub repository!
Thanks for reading!

脚注
Post by Common Service Development Group Member 1

[Implementing Domain-Driven Design (DDD) in Payment Platform with Global Expansion in Mind ] ↩︎
Post by Common Service Development Group Member 2

[Success Story: New System Development through Remote Mob Programming by Team Members with Less Than One Year Experience] ↩︎
Post by Common Service Development Group Member 3

[Improving Deploy Traceability Across Multiple Environments Using JIRA and GitHub Actions] ↩︎
Post by Common Service Development Group Member 4

[ Development Environment Setup Using VSCode Dev Container ] ↩︎
Post by Common Service Development Group Member 5

[ Guide to Setting Up S3 Local Development Environment Using MinIO (AWS SDK for Java 2.x) ] ↩︎

Capability	Implementation	Example
Sequential	Chain multiple jobs	Daily data processing pipeline
Error Handling	Define recovery actions	Automated error notifications
Concurrent	Run multiple jobs simultaneously	Parallel data processing
Parallel	Multiple instances of same job	Large dataset processing

Aspect	Chunk	Tasklet
Data Volume	Suitable for large volumes	Suitable for small volumes
Processing Complexity	Suitable for complex processing	Suitable for simple processing
Management Cost	Higher	Lower
Debugging	Somewhat complex	Easy
Transaction	By chunk	By process unit

関連記事 | Related Posts

December 9, 2023

Spring Bootを2系から3系へバージョンアップしました。

January 29, 2024

Spring Boot 2 to 3 Upgrade: Procedure, Challenges, and Solutions

April 25, 2024

Spring BatchとDBUnitを使ったテストで起きた問題

July 15, 2024

An Issue We Encountered During Testing With Spring Batch using DBUnit

September 18, 2024

Flyway Implementation

October 10, 2024

Efforts to Improve Deploy Traceability to Multiple Environments Utilizing GitHub and JIRA

We are hiring!

【データエンジニア】分析G／名古屋・大阪

分析グループについてKINTOにおいて開発系部門発足時から設置されているチームであり、それほど経営としても注力しているポジションです。決まっていること、分かっていることの方が少ないぐらいですので、常に「なぜ」を考えながら、未知を楽しめるメンバーが集まっております。

【スクラッチ開発エンジニア】プラットフォームG／東京・大阪

プラットフォームグループについてAWS を中心とするインフラ上で稼働するアプリケーション運用改善のサポートを担当しています。

Quick Start Spring Batch with Spring Boot 3

Yohei Miyashita

Contents

Introduction

Target Audience

Repository Setup

Repository Structure

Skeleton Batch Guide

Core Concepts: Jobs and Steps

Jobs

Step

Implementation Method

1. Chunk Processing

Implementation Characteristics

2. Tasklet Processing

Characteristics

Choosing Between Implementation Methods

Summary

YAML Configuration and Spring Batch Management Tables

YAML Configuration

Spring Batch Management Tables

Job Class Guide

Class Definition Key Points

Dependency Class Roles

Processing Flow

Transaction Management

Logic Class Guide

Class Definition Key Points

Processing Flow

Error Handling

Service Class Guide

Class Definition Key Points

Customization Options

Running the Batch

Running from IDE

Running via Gradle from Terminal

Running by Generating and Executing JAR File

Checking Execution Logs

1. Job Registration Check

2. Batch Processing Execution

Important Points from Logs:

Skeleton Batch Summary

Advantages

DB and CSV Batch Guide

Overview

Local Database Setup

Entity Class Auto-generation

Running Auto-generation

Generated Entity Classes

Example output:

Handling "Class Not Found" Errors

Production Environment Setup

Multi-database Configuration

Configuration File (application-local.yml)

Data Source Configuration Class

Key Annotations

Job Class Guide

New Features Added

Logic Class Guide

Parameter Configuration

Error Handling

Repository Class and jOOQ Guide

About jOOQ

Select Processing

Key Features

Bulk Insert Processing

Bulk Insert Features

Repository Class Summary

DB to CSV Batch Execution Guide

Running via Gradle

Running JAR File

Why This Error Occurs

Running with Arguments

Example Commands

Examining the Logs

1. Initial Startup Log

2. Job Start Log

3. Database Operation Log

Generated CSV Check

Testing Runtime Argument Override

2.　Tasklet Processing
